MG80 Multipurpose Gauge
BLUM part no. 241530
Generation 2 multipurpose gauge for in-machine temperature and pressure measurement, transmitting by radio to an RC66 receiver. Takes up to four temperature and four pressure sensors.
Technical data
Generation 2
Temperature inputs4 (T1–T4)
Temperature range−5 °C to +80 °C
Temperature accuracy±1 K absolute at 20 °C
Temperature linearity±2 K over range
Pressure inputs4 (P1–P4)
Pressure ranges0–200 bar (4.5 V), 0–600 bar (5 V)
Pressure accuracy±1% absolute at 20 °C
Protection classIP 67
Signal transmissionRadio, 2.400–2.4835 GHz
ReceiverRC66
Battery2 × 3.6 V AA lithium (LS 14500)
Mounting2 × M5, O-ring 55×3
Application notes
Used for process monitoring inside the machine — coolant and spindle temperatures, clamping and coolant pressures — on the same radio channel as the probing system.
Documentation
BLUM drawings and manuals are supplied under Blum-Novotest's ISO 16016 confidentiality notice, so they are released on request rather than published here.
