BLUM-Novotest · Radio system
IF20 Interface
BLUM part no. 184560
DIN rail interface between the RC66 radio receiver and the machine control. Accepts optional extension modules and supplies the receiver.
Technical data
Mounting DIN rail, DIN EN 50022-35
Dimensions128 × 102 × 52 mm
BusBLUM TBUS to DIN rail
Supplies13 V to RC66
Extension modulesOptional, e.g. EM30
Pairs withRC66 radio receiver
Application notes
The IF20 is the current interface for radio systems; the older IF59-A2 (142821) performs the same role at 12 V. Electrical connection detail is in the IF20 installation instructions.
Documentation
BLUM drawings and manuals are supplied under Blum-Novotest's ISO 16016 confidentiality notice, so they are released on request rather than published here.
