Ceramic Stylus L50mm D5mm
BLUM part no. 143747
Ceramic stylus with ruby ball for TC-series touch probes. Styli are wear parts and are treated as consumables.
Technical data
Stylus length 50 mm
Ball diameter5 mm
Ball materialRuby
Shaft materialCeramic
For probe seriesTC (incl. TC62)
Deflection at 50 mm11 mm X/Y on TC62
Measuring force at 50 mm1.5 N on TC62
Application notes
Ceramic shafts are chosen where a collision should break the stylus rather than the probe. Changing stylus length changes both deflection and measuring force, so the probe must be recalibrated after a change.
Documentation
BLUM drawings and manuals are supplied under Blum-Novotest's ISO 16016 confidentiality notice, so they are released on request rather than published here.
