TC62 Touch Probe
BLUM part no. 142892
Radio workpiece touch probe for in-machine part setting and inspection. Sub-micron trigger repeatability with permanent collision control, transmitting to an RC66 receiver.
Technical data
Trigger repeatability 0.3 µm 2σ (30 mm stylus)
Approach directions±X, ±Y, −Z
Max deflection X/Y±11°
Max deflection Z6 mm
Measuring force Z5.7 N
Protection classIP 68
Signal transmissionRadio, 2.400–2.4835 GHz
ActivationRadio
ReceiverRC66
ShankBTH 25 tool holder
Battery2 × 3.6 V 1/2AA lithium (LS 14250)
Max acceleration50 m/s²
Mass250 g
Collision controlPermanent
Application notes
Measuring force and deflection vary with stylus length: 30 mm gives 7 mm deflection at 2.3 N, 50 mm gives 11 mm at 1.5 N, 75 mm gives 16 mm at 1.1 N and 100 mm gives 20 mm at 0.8 N. Quoted repeatability is stated at 30 mm.
Documentation
BLUM drawings and manuals are supplied under Blum-Novotest's ISO 16016 confidentiality notice, so they are released on request rather than published here.
